C7012A,C,E,F,G SOLID STATE PURPLE PEEPER® ULTRAVIOLET FLAME DETECTORS
60-2398-17 10
Fig. 12. Wiring diagram for C7012E or F Detectors with
R4075E (currently obsolete) Flame Safeguard Control.
Fig. 13. Wiring diagram for C7012E or F Detectors with
R4138C,D (currently obsolete) Flame Safeguard controls.
Fig. 14. Wiring diagram for C7012E or F Detectors with
R4140, and BC7000 (currently obsolete), and R7140 Flame
Safeguard controls.
Fig. 15. Wiring diagram for C7012E,F Detectors
with BCS 7700 (currently obsolete) Flame Safeguard
controls.
WHITE
WHITE
BLUE
BLACK
BLACK
M9373
G
F
13
12
3
L2
4
C7012E,F
2
TERMINAL STRIP
FOR R4075E
ON SUBBASE
1
AN R7247C DYNAMIC SELF-CHECK AMPLIFIER MUST BE USED WITH
AN R4075E.
TWO C7012E OR F DETECTORS CAN BE CONNECTED IN PARALLEL
TO THE SAME TERMINALS ONLY ON 120 VOLT CONTROLS.
WIRING IS SHOWN FOR SECTION B. CONNECT ANOTHER DETECTOR
TO THE IDENTICAL TERMINALS IN SECTION A. TERMINAL L2 IS
USED FOR BOTH SECTIONS.
VOLTAGE AND FREQUENCY RATING OF THE C7012E OR F MUST
MATCH THE POWER SUPPLY OF THE FLAME SAFEGUARD CONTROL.
( ) IDENTIFICATION LABEL ON LEADWIRES.
2
3
4
5
5
1
3
YELLOW
L1
(POWER SUPPLY)
SECTION B
(L1)
(L2)
(S)
(L2)
BLUE
YELLOW
WHITE
WHITE
BLACK
(L1)
(L2)
(L2)
(S)
BLACK
M9374
14
13
12
F
G
9
8
7
3
L1
L2
3
4
5
C7012E,F
2
TERMINAL STRIP
FOR R4138C OR D
IN CABINET
OR ON SUBBASE
JUMPER
1
AN R7247C DYNAMIC SELF-CHECK AMPLIFIER MUST BE USED WITH
AN R4138C OR D.
TWO C7012E OR F DETECTORS CAN BE CONNECTED IN PARALLEL
WITH THE SAME TERMINALS ONLY ON 120 VOLT CONTROLS.
REMOVE THE JUMPERS BETWEEN TERMINALS 14 AND 13 AND
BETWEEN TERMINALS 12 AND F (IF THERE ARE JUMPERS),
AND INSTALL A JUMPER BETWEEN TERMINALS 13 AND 7.
VOLTAGE AND FREQUENCY RATING OF THE C7012E OR F MUST
MATCH THE POWER SUPPLY OF THE FLAME SAFEGUARD CONTROL.
( ) IDENTIFICATION LABEL ON LEADWIRES.
2
3
4
1
5
WHITE
YELLOW/GREEN
M9375A
C7012E OR F
3
1
AN R7247C DYNAMIC SELF-CHECK AMPLIFIER MUST BE USED WITH
AN R4140, BC7000.
VOLTAGE AND FREQUENCY RATING OF THE C7012E OR F MUST
MATCH THE POWER SUPPLY OF THE FLAME SAFEGUARD CONTROL.
TWO C7012E OR F DETECTORS CAN BE CONNECTED IN PARALLEL
WITH THE SAME TERMINALS ONLY ON 120 VOLT CONTROLS.
THE ADDITIONAL YELLOW/GREEN LEADWIRE IS ONLY ON C7012E
MODELS DESIGNED TO MEET DIN OR BGC REQUIREMENTS;
CONNECT THIS WIRE TO A SEPARATE GROUND TERMINAL ON THE
WIRING SUBBASE.
( ) IDENTIFICATION LABEL ON LEADWIRES.
2
3
4
5
5
YELLOW
WHITE
4
G
17
F
L2
L1
BLACK
BLACK
BLUE
2
TERMINAL STRIPS FOR R4140 OR
BC7000 ON Q520A WIRING SUBBASE
1
(S)
(L2)
(L1)
(L2)
WHITE
YELLOW
WHITE
M9376
31
29
27
L2
L1
L2
4
C7012E,F
3
BCS 7700
TERMINAL STRIP
1
A R7747C DYNAMIC SELF-CHECK AMPLIFIER MUST BE USED
WITH THE C7012E,F/BCS 7700 COMBINATION. SHUTTER
CYCLE RATE IS 12 TIMES PER MINUTE. USE SERIES 7 OR
GREATER FOR THESE APPLICATIONS.
VOLTAGE AND FREQUENCY RATING OF THE C7012E,F MUST
MATCH THE POWER SUPPLY OF THE FLAME SAFEGUARD
CONTROL.
TWO C7012E,F DETECTORS CAN BE CONNECTED IN PARALLEL
TO THE SAME TERMINALS ONLY ON 120 VOLT CONTROLS.
THE ADDITIONAL YELLOW/GREEN LEADWIRE IS ONLY ON
C7012E MODELS THAT MEET BGC OR DIN REQUIREMENTS;
CONNECT YELLOW/GREEN WIRE TO A SEPARATE GROUND
TERMINAL ON THE WIRING SUBBASE.
( ) IDENTIFICATION LABEL ON LEADWIRES.
2
3
4
5
5
1
2
BLUE
BLACK
BLACK
YELLOW/GREEN
(S)
(L2)
(L2)
(L1)
To Next Page
