C7012A,C,E,F,G SOLID STATE PURPLE PEEPER® ULTRAVIOLET FLAME DETECTORS
60-2398-17 2
DISPOSAL
Devices with electronic components:
WEEE Directive 2012/19/EU – Waste Electrical and Electronic Equipment Directive
At the end of the product life (number of operating cycles reached), dispose of the packaging and product in a
corresponding recycling center. Do not dispose of the unit with the usual domestic refuse. Do not burn the product.
On request, old units may be returned carriage paid to the manufacturer in accordance with the relevant waste
legislation requirements.
• Oscillating shutter interrupts ultraviolet radiation
reaching UV sensor between 60 and 120 times per
minute (10 times per minute with R7747C dynamic
self-check amplifiers) to provide the UV sensor tube
checking function. Amplifier circuitry components
are checked from the microprocessor in the BCS 7700
or 7800 SERIES Control.
C7012A,E,G
• Housing meets NEMA 4 enclosure standards
(indoor, outdoor protection: rain-tight, dust-tight,
hose-directed watertight).
• Protective heat block built into mounting flange.
• High pressure 50 psi (345 kPa) quartz viewing window,
focusing lens, swivel mount and antivibration
mounting accessories available.
C7012C,F
• Housing designed to be explosion-proof and
Underwriters Laboratories Inc. listed for use in
hazardous locations; Class I, groups C and D;
and Class II, groups E, F, and G.
• Viewing window rated for 100 psi (690 kPa).
SPECIFICATIONS
IMPORTANT
The specifications in this publication do not include
normal manufacturing tolerances. Therefore, this
unit may not exactly match the specifications listed.
This product is tested and calibrated under closely
controlled conditions, and minor differences in
performance can be expected if those conditions
are changed.
Models:
C7012A Solid State Purple Peeper® Ultraviolet Flame
Detector: For use in rectification type flame safeguard
systems.
C7012C Solid State Purple Peeper® Ultraviolet Flame
Detector: Same as C7012A except with explosion-proof
housing for use in hazardous locations.
C7012E Self-Checking Solid State Purple Peeper® Ultraviolet
Flame Detector: For use with R7247C, and R7847C
Dynamic Self-Check Amplifiers.
C7012F Self-Checking Solid State Purple Peeper® Ultraviolet
Flame Detector: Same as C7012E except with
explosion-proof housing for use in hazardous locations.
C7012G Solid State Purple Peeper® Ultraviolet Flame
Detector: Same as C7012A except designed to meet
BGC (British) and DIN (German) requirements.
Electrical Ratings:
Voltage and Frequency:
C7012A: Separate models for 100, 120, 208, or 240 Vac,
all 50/60 Hz
C7012E: Separate models for 100, 120, 208, or
240 Vac, all 50/60 Hz; also models for 110 or 220 volts,
50 Hz only.
C7012C and F: 120 Vac, 50/60 Hz.
C7012G: Models for 220 volts, 50 Hz only.
Power Consumption:
C7012A,C and G: 2.5 watts maximum.
C7012E and F: 7.0 watts maximum.
Ambient Operating Temperature Ratings
(Outside the Case):
C7012A,C and G: 25°F to 175°F (-4°C to 79°C).
C7012E and F: -20°F to 175°F (-29°C to 79°C).
C7012A1160 and C7012E1120: -40°F to 175°F
(-40°C to 79°C).
Storage Temperature Ratings:
-60°F to 175°F (-51°C to 79°C).
Housing:
C7012A,E and G: Violet, cast-aluminum cover; mounting
flange (with heat block) and faceplate are separate to
provide heat insulation and sealoff. Meets NEMA 4
enclosure requirements (indoor, outdoor protection;
rain-tight, dust-tight, hose-directed water). Optional water
jacket available for the C7012A,E,G.
C7012C and F: Explosion-proof, two-piece, violet, cast
aluminum.
Pressure Rating Of Quartz Viewing Window:
C7012A,E and G: 20 psi (138 kPa). Focusing lens:
20 psi (138 kPa) rating or high pressure viewing window
50 psi (345 kPa) rating available; see Accessories section.
C7012C and F: 100 psi (690 kPa).
Mounting:
C7012A and E: Mounting flange with either 3/4 or 1 inch NPT
internal threads (depending on model) for attaching to
sight pipe.
