Honeywell R4348B Series - Page 3

3 EN1C-9999SZ22 R1104
FIG. 1 Dimensions in mm.
FIG.2 Main features
ACCESSORIES:
Subbase : 46176612-501 : for IP40 (to be ordered separately)
158
88
88
TOP VIEW
11x Pg11
ø4,5
3015
30
30
45
82
200
100
15
45
20 (minimum) required for unplugging
R4348B from the subbase
20
Front view
Rear view
subbase
