Honeywell R4348B Series User Manual

EN1C-9999SZ22 R1104 2
SPECIFICATIONS
WARNING
To avoid the risk of electrical shock which could
cause personal injury, follow all safety notices in this
documentation.
MODEL:
R4348B industrial flame switch with 3-pole flame relay
and 3-pole load relay
1)
see OPTIONS also
ELECTRICAL RATINGS:
can operate on 110V - 120V - 127V - 230V 50/60Hz
POWER CONSUMPTION:
less than 15VA
ENCLOSURE:
IP40 or IP54 depending on the model and base
AMBIENT TEMPERATURE LIMITS:
Operating: - 20°C to + 60°C.
Storage: - 40°C to + 80°
CLASSIFICATION:
OOCRXB
APPROVALS:
Installation and cabling for both intermittent and
continuous operations must be in accordance with
relevant standards (i.e. EN298)
OPTIONS: (see MODELS also)
LED-METER. A series of color coded LED’s on the face of
the unit which give a direct indication of flame current
strength.
Green LED’s indicate normal flame current strength. Yellow
LED’s indicate marginal signals. Red LED’s indicate
unsatisfactory flame signal strength (see fig. 2).
4-20mA OUTPUT. The flame current value can be
registered and/or displayed at a local or remote location.
Load : 0 to 750Ω.
.
CONTACT RATINGS:
If more than one safety shut-off valve is to be actuated by
the R4348 it is recommended to use separate relay contacts
rather than paralleling from one contact.
MAXIMUM RELATIVE HUMIDITY:
90 % RH at 40oC (not to exceed saturation point)
WEIGHT : 1,5 Kg
FLAME SENSORS AND AMPLIFIERS :
will accept any of the plug-in amplifiers and appropriate
sensor listed .
FLAME INDICATION :
Green LED on face of unit when illuminated indicates
presence of flame. Relay contact enables remote indica-
tion of flame presence to be made.
MOUNTING :
Can be wall, DIN rail of panel mounted.
Subbase: 46176612-501
SREBMUNLEDOMSETON
)1
8001B8434Rledomdradnats
7501B8434RtuptuoAm02-4htiw
retem-DELdna
daoL
lacipyT
rewop
rotcaf
tnerrucmumixaM
suounitnoc(gnitar
)noitarepo
mumixaM
hsur-nI
tnerruc
V032
V011
V021
V721
dioneloS
evlav
4.0A5.1A2detarx01
tnerruc
dezirotoM
evlav
5.0A2A4detarx3
tnerruc
renruB
rotom
6.0A3A3detarx5
tnerruc
noitingI
remrofsnart
2.0A5.2A4detar
tnerruc
rehtO59.0A4A4detar
tnerruc
