EN2R-9053 0408R11-NE 4
DIMENSIONAL DRAWING S4965 BOILER CONTROL
Molex Minifit (for X1) and Microfit (for X11 and X12) can be
used as alternatives
Dimension cover
110
115
120
117
82
64
46
17
12
61
14
33
24
16
1
6
3
1
1
8
9
16
18
15
10
X11X12X1
Material : ABS - V0
Tolerances ± 1 mm
unless noted
FOR CONNECTORS, USE FEMALE PARTS
Plastic part Pins Terminal
X1 TYCO 1-106527-0 10 TYCO 106528-2 (reel)
(for AWG 22-26, insulation
diameter 1,20 - 1,75 mm)
X11 TYCO 794617-6 6
TYCO 794607 (reel)
TYCO 794611
(for AWG 26-30)
X12 TYCO 1-794617-6 16
X12 TYCO 1-794617-8 18
6,6 ± 0,4
3,3 ± 0,3
68,1 ±0,3
33,4
74,65
48,2
Material : ABS - V0
Tolerances ± 1 mm
unless noted
