12
CANOPY INSTALLATION
18. Lift the canopy up so the partially installed mounting
bracket screws are situated in the L-slots on each
side of the canopy. Rotate the canopy clockwise
and install the remaining mounting bracket screws
and washers from Step 4 (Fig. 18).
Mounting
Bracket
Mounting
Bracket Screw
and Washer
Canopy
Mounting Bracket
Screw
Washer
Fig. 18
