Building-Specific Operation and Programming Examples The SCS⁄SCE
Point assignments for SCS at address 5:
The control modules which control the ON capability of the fans are configured as Form-C relays when in a Non-dedicated system. See Sec-
tion 4.2, The Control Module, for more information.
Point Assignments: classification type ID Point Assignments: classification type ID
1(CON
ON⁄OP
) needed AFCM 17 (CON
ON⁄OP
) unneeded -
2(CON
OFF⁄CL
) unneeded - 18 (CON
OFF⁄CL
) needed ACON
3(VER
ON⁄OP
) needed AMON 19 (VER
ON⁄OP
) unneeded -
4 (VER
OFF⁄CL
) unneeded - 20 (VER
OFF⁄CL
) needed AMON
5(CON
ON⁄OP
) needed AFCM 21 (CON
ON⁄OP
) unused ACON
6(CON
OFF⁄CL
) unneeded - 22 (CON
OFF⁄CL
) unused ACON
7(VER
ON⁄OP
) needed AMON 23 (VER
ON⁄OP
) unused ACON
8 (VER
OFF⁄CL
) unneeded - 24 (VER
OFF⁄CL
) unused ACON
9(CON
ON⁄OP
) needed AFCM 25 (CON
ON⁄OP
) unused ACON
10 (CON
OFF⁄CL
) unneeded - 26 (CON
OFF⁄CL
) unused ACON
11 (VER
ON⁄OP
) needed AMON 27 (VER
ON⁄OP
) unused ACON
12 (VER
OFF⁄CL
) unneeded - 28 (VER
OFF⁄CL
) unused ACON
13 (CON
ON⁄OP
) needed AFCM 29 (CON
ON⁄OP
) unused ACON
14 (CON
OFF⁄CL
) unneeded - 30 (CON
OFF⁄CL
) unused ACON
15 (VER
ON⁄OP
) needed AMON 31 (VER
ON⁄OP
) unused ACON
16 (VER
OFF⁄CL
) unneeded - 32 (VER
OFF⁄CL
) unused ACON
Point Assignments: classification type ID Point Assignments: classification type ID
33 (CON
ON⁄OP
) unused ACON 49 (CON
ON⁄OP
) unused ACON
34 (CON
OFF⁄CL
) unused ACON 50 (CON
OFF⁄CL
) unused ACON
35 (VER
ON⁄OP
) unused ACON 51 (VER
ON⁄OP
) unused ACON
36 (VER
OFF⁄CL
) unused ACON 52 (VER
OFF⁄CL
) unused ACON
37 (CON
ON⁄OP
) unused ACON 53 (CON
ON⁄OP
) unused ACON
38 (CON
OFF⁄CL
) unused ACON 54 (CON
OFF⁄CL
) unused ACON
39 (VER
ON⁄OP
) unused ACON 55 (VER
ON⁄OP
) unused ACON
40 (VER
OFF⁄CL
) unused ACON 56 (VER
OFF⁄CL
) unused ACON
41 (CON
ON⁄OP
) unused ACON 57 (CON
ON⁄OP
) unused ACON
42 (CON
OFF⁄CL
) unused ACON 58 (CON
OFF⁄CL
) unused ACON
43 (VER
ON⁄OP
) unused ACON 59 (VER
ON⁄OP
) unused ACON
44 (VER
OFF⁄CL
) unused ACON 60 (VER
OFF⁄CL
) unused ACON
45 (CON
ON⁄OP
) unused ACON 61 (CON
ON⁄OP
) unused ACON
46 (CON
OFF⁄CL
) unused ACON 62 (CON
OFF⁄CL
) unused ACON
47 (VER
ON⁄OP
) unused ACON 63 (VER
ON⁄OP
) unused ACON
48 (VER
OFF⁄CL
) unused ACON 64 (VER
OFF⁄CL
) unused ACON
