5 Selection of parameter presettings for a hydraulic
unit
In the state of delivery, each controller type covers multiple
hydraulic units. Each hydraulic unit can be changed or expanded
by changing and/or adding parameters.
A hydraulic unit is selected with parameter 01 in the "Hydraulics"
menu. The corresponding inputs and outputs are assigned
automatically based on the hydraulics schematic.
This function simplifies the setting of a documented hydraulic unit
considerably.
Additional applications can be covered by setting the individual
parameters. Where necessary, the parameters are also specified
in these mounting instructions. A description of how to access
parameter settings can be found in the parameter list.
Operating in-
formation
Menu
Parameter
Enter
schematic, e.g.
Hydraulics
preselection
"Hydraulics"
01
0201
Pos: 9 /156-Honeywell/M ontage/Ap plikationen @ 1\ mod_12085 07778701_6.doc @ 11085
6 Applications
See chapter 10 Εφαρμογές θέρμανσης / Heating applications pg. 46
and chapter 11 Εφαρμογές τηλεθέρμανσης /
District heating applications pg. 73.
