Honeywell SDC 9-21 - Page 56

Εφαρμογές θέρμανσης / Heating applications SDC
56 MU1H-0438GE51 R0313
10.7.2 Υδραυλικό σύστημα 0305.2 (SDC 12-31)
Hydraulics 0305.2 (SDC 12-31)
X 1 X 2 X 3 X 4
23 GND 19 1 T2 10
24 BUS A 20 2 T1 11
25 BUS B 21 N 3 12 L1
26 22 L1 4 13 R2
27 WF2 5 14 R2
28 6 L 1 15 KP2
29 VF2 7 MK2 16 T7
30 8 MK2 17 T8
31 9 P2 18 T6
32
33 RLF2
34
35
36
37
38
X 5 X 6 X 7 X 8 X 9 X 10
1 Bus B 1 Bus A 1 T1 1 T2 1 N 1 PE
2 GND 2 2 2 2 N 2 PE
3 GND 3 WF 2 3 3 3 N 3 PE
4 GND 4 4 4 MK2 4 N 4 PE
5 GND 5 VF 2 5 L 1 5 MK2 5 N 5 PE
6 GND 6 6 6 P 2 6 N 6 PE
7 GND 7 7 7 7 N 7 PE
8 GND 8 8 8 8 N 8 PE
9 GND 9 RLF2 9 T6 9 R2 9 N 9 PE
10 GND 10 10 T8 10 R2 10 N 10 PE
11 GND 11 11 T7 11 KP2 11 N 11 PE
12 GND 12 12 N 12 PE
13 N 13 PE
Εισαγωγή παραμέτρων β 10.7.2.1 σελ. 57
For parameter entry, see 10.7.2.1 pg. 57.
X1X2
X4
X3
ΥΠΟΔΕΙΞΗ
NOTE
