SDC Εφαρμογές τηλεθέρμανσης / District heating applications
MU1H-0438GE51 R0313 85
11.13 Υδραυλικό σύστημα 0512 (SDC 12-31, τρόπος λειτουργίας DHC)
Hydraulics 0512 (SDC 12-31, DHC mode)
X 1 X 2 X 3 X 4
23 GND 19 1 V1 10 ZKP
24 BUS A 20 2 L 1 11
25 BUS B 21 N 3 DKP 12 L 1
26 AF 22 L 1 4 13
27 VF1 5 SLP 14
28 SF 6 L 1 15
29 VF 2 7 MK1 16 V1
30 VFB2 8 MK1 17
31 VE2 9 18 L 1
32 VFB
33
34
35
36
37
38
X 5 X 6 X 7 X 8 X 9 X10
1 Bus B 1 Bus A 1 1 V1 1 N 1 PE
2 GND 2 AF 2 2 DKP 2 N 2 PE
3 GND 3 VF1 3 3 SLP 3 N 3 PE
4 GND 4 SF 4 4 MK1 4 N 4 PE
5 GND 5 VF 2 5 L 1 5 MK1 5 N 5 PE
6 GND 6 VFB2 6 6 6 N 6 PE
7 GND 7 VE2 7 7 ZKP 7 N 7 PE
8 GND 8 VFB 8 8 8 N 8 PE
9 GND 9 9 9 9 N 9 PE
10 GND 10 10 10 10 N 10 PE
11 GND 11 11 V1 11 11 N 11 PE
12 GND 12 12 N 12 PE
13 N 13 PE
Pos: 45 /156-Honeywell/ Montage/051 3/SDC12-31 @ 1\mod_12076 53221822_ 258.doc @ 10 626
X1X2
X4
X3
