Honeywell ST9400A User Manual

6
PROGRAMMING YOUR ST9400A
The Built-in Programmes
The built-in programmes give you a starting point that you can personalise to your
own requirements. Your Installer should have selected one and ticked the box
alongside it. If there is no tick, the product normally leaves the factory with Profile A
installed, but it is a simple matter to select one of the other profiles (see Changing
the Installer Parameters, page 12).
Built-in Programme (Profile A)
ON 1 OFF 1 ON 2 OFF 2 ON 3 OFF 3
Heating
6:30am 8:30am 4:30pm 10:30pm Not used Not used
Hot Water
6:30am 8:30am 4:30pm 10:30pm Not used Not used
Your Personal Programme
The table below has been left blank for you to record your own personal programme.
For ease of use, your ST9400A is supplied as standard with only 2 on/off’s enabled. To
enable ON/OFF period 3 see Fine Tuning your ST9400A (page 12).
Built-in Programme (Profile b)
ON 1 OFF 1 ON 2 OFF 2 ON 3 OFF 3
Heating
6:30am 9:30am 4:30pm 11:00pm Not used Not used
Hot Water
6:30am 9:30am 4:30pm 11:00pm Not used Not used
Built-in Programme (Profile C)
ON 1 OFF 1 ON 2 OFF 2 ON 3 OFF 3
Heating
6:30am 7:30am 5:00pm 10:00pm Not used Not used
Hot Water
6:30am 7:30am 5:00pm 10:00pm Not used Not used
ON 1 OFF 1 ON 2 OFF 2 ON 3 OFF 3
Heating
Hot Water

Honeywell ST9400A Specifications

General

Model	ST9400A
Category	Thermostat
Voltage	230V AC
Switching Current	3A
Mounting	Wall-mounted
Display	LCD
Battery Backup	No
Contact Voltage	230V AC
Frequency	50Hz
Type	Programmer
Switch Rating	3A
Temperature Range	5°C to 30°C
Contact Rating	3A
