T7560A,B,C DIGITAL WALL MODULES
3 EN0B-0237GE51 R0509
Field Wiring
16 to 22 AWG (1.5 to 0.34 mm
2
) depending on
application.
18 AWG (1.0 mm
2
) min. for 24 Vac power wiring.
Max. length of wire from a device to a wall module is
164 ft (50 m).
Twisted pair wire recommended for wire runs longer than
100 ft (30.5 m).
Setpoint Adjustment Range (A and B)
Setpoint can be configured for
Fahrenheit absolute (55...85 °F)
Fahrenheit relative (± 10)
Celsius absolute (12...30 °C)
Celsius relative (± 5)
Temperature Value Display Resolution (A and B)
Degree Celsius 0.1 °C
Degree Fahrenheit 0.1 °F
Setpoint Value Display Resolution (A and B)
Degree Celsius 0.5 °C
Degree Fahrenheit 1.0 °F
Mounting Options
Wall mounting
Dimensions (H/W/D)
4-1/8 x 3-15/16 x 1-3/16 in. (104 x 99 x 30 mm)
Environmental Ratings
Shipping temperature: -22...+140 °F (-30...60 °C)
Operating temperature: 32...104 °F (0...+40 °C)
Relative humidity: 5...95% non-condensing
Measurement range: +6…+40 °C
Approval Bodies
UL 916, NEC Class 2
CE
