T775P SERIES 2000 ELECTRONIC STAND-ALONE CONTROLLER
62-0256—11 10
Fig. 15. LCD Display - Home Screen Displaying
Sensors, Stages, and Pump Out.
NOTES:
1. The stage home screens do not dynamically
update the active relay status and sensor val-
ues. The information is a snapshot taken
when you press the or button to display
the screen.
2. In Reset mode, the home screen displays the
effective setpoint.
IMPORTANT
After four minutes of inactivity (no buttons
pressed), the LCD display reverts to the home
screen display.
Accessing the Menus
Menus are used for programming, scheduling, viewing the
summary settings, and setup of advanced options.
Program, Schedule, and Summary
Menus
To access these menus from the home screen, press the
MENU button. See Fig. 16.
Fig. 16. Menus.
Depending on whether scheduling is enabled or not, the
LCD displays one of two menus as shown in Fig. 16.
Scheduling is enabled from the Setup menu’s Output
settings. See “1.3.2. SCHEDULE” on page 16.
Setup Menu
To access the Setup menu for advanced options, press
and hold the MENU button for five seconds. See Fig. 17.
Fig. 17. Setup Menu.
Using the Menus
When you are working with the menus, use the:
• Left arrow button () to scroll backward through the
menus
• Right arrow button () to select the highlighted menu
item and display its content
• Up and Down arrow buttons ( and ) to scroll up
and down through a list of items or to increase or
decrease the value of a displayed parameter
NOTE: If you press the HOME button or there is no
keypad activity for four minutes, you exit
Setup mode and return to the home screen.
If you press the MENU button, you exit Setup.
mode and go to the Program menu.
DI ON
HOME
1
2
3
4
5
6
7
8
9
10
11
12
SENSORS
SUPPLY A
180.5
OUTDOOR B
72.5
o
o
F
F
DI ON
HOME
o
F
o
F
STG1 ON
SETPOINT
66.0
SUPPLY A
180.5
RT 1476 HRS
1
2
3
4
5
6
7
8
9
10
11
12
RETURN C
100.5
o
F
DI ON
HOME
o
F
o
F
STG2 ON
SETPOINTT
66.0
OUTDOOR B
72.5
RT 832 HRS
1
2
3
4
5
6
7
8
9
10
11
12
DI ON
HOME
o
F
o
F
STG3 OFF
SETPOINT
66.0
RETURN C
100.5
RT 1193 HRS
1
2
3
4
5
6
7
8
9
10
11
12
DI ON
HOME
o
F
o
F
STG4 ON
SETPOINTT
66.0
SUPPLY A
180.5
RT 1287 HRS
1
2
3
4
5
6
7
8
9
10
11
12
PUMP OUT
M24394
MENU
PROGRAM
EXIT
home
menu
OR
MENU DISPLAY WHEN
SCHEDULING IS NOT SET
MENU DISPLAY WHEN
SCHEDULING IS SET
MENU
DI ON
HOME
SENSORS
PROGRAM
SCHEDULE
SUMMARY
EXIT
1 2 3 4 5 6 7 8 9 10 11 12
SUPPLY A
180.5
OUTDOOR B
72.5
o
o
F
F
RETURN C
100.5
o
F
M24395
home
menu
SETUP
DI ON
HOME
FIVE
SECONDS
SENSORS
SENSORS
OUTPUTS
ALARMS
EXIT
1
2
3
4
5
6
7
8
9
10
11
12
SUPPLY A
180.5
OUTDOOR B
72.5
o
o
F
F
RETURN C
100.5
o
F
M24396
To Next Page
