Fig. 53. Setup Pump - Postpurge.
1.3.7.4. POSTPURGE
1. From the Stage/Pump menu, use the  and 
buttons to select POSTPURGE.
2. Press the  button to display the postpurge time.
3. Use the  and  buttons to increase/decrease the
postpurge time.
Default: 0 (zero) seconds
Range: 0 to 3600 seconds
4. Press the  button to accept the value and display
the Stage/Pump menu.
NOTE: A positive Postpurge time causes the pump
to run for the set number of seconds after the
last stage de-energizes.
Fig. 54. Setup Pump - Exit.
1.3.7.5. Pump Exit
Press the  button (or highlight EXIT and press the 
button) to exit the current Stage/Pump menu and return to
the Outputs menu.
This completes the pump setup. Continue with “1.4. Setup
Alarms”.
Fig. 55. Setup Alarms.
1.4. Setup Alarms
1. From the Setup menu, use the  and  buttons to
highlight the Alarms.
2. Press the  button to display the Alarms menu.
There are three alarms available, High, Low, and
Differential. When an alarm is selected, its alarm limit
selection displays on the Alarms menu.
When an alarm is active, the Digital Output (D.O.) closes
and “ALARM” displays on the home screen.
NOTE: Low and differential relay alarms require the
condition to prevail for 5 minutes before
contacts will close.
Fig. 56. Setup High Alarm.
1.4.1. HIGH ALARM
Only Sensor A can be used to sense the high alarm
temperature. Sensor C cannot be used.
1. From the Alarms menu, use the  and  buttons to
select HI ALARM.
2. Press the  button to display the alarm options.
3. Use the  and  buttons to select YES or NO.
Default: NO
4. Press the  button to accept the value and display
the Alarms menu.
Selecting YES displays the HI LIMIT option on the Alarms
menu once you exit this screen. Continue with “1.4.1.1.
HIGH LIMIT” on page 24.
For systems with no high limit alarm, select NO, press
the  button, and continue with “1.4.2. LOW ALARM” on
page 24.
