Honeywell TC500A Mounting Instructions

TC500A-N/TC500A-W COMMERCIAL THERMOSTAT
® U.S. Registered Trademark
© 2021 Honeywell International Inc.
31-00399M-02 | Rev.03-21
Honeywell Building Technologies
Honeywell
715 Peachtree Street NE
Atlanta, GA 30308
customer.honeywell.com
buildingcontrols.honeywell.com
DIMENSIONS
3 -19/32 ” (91.2 mm)
4 - 15/32”
(113.7 mm)
4 x 11/32”
(9mm)
2 - 3/8”
(60.3mm)
3 - 1/4”
(82.75mm)
4 x 3/16”
(4.5mm)

Honeywell TC500A Specifications

General

Brand	Honeywell
Model	TC500A
Category	Thermostat
Language	English
