Honeywell TC500A Quick Start Guide

TC500A COMMERCIAL THERMOSTAT
3 31-00398M-02 | Rev. 04-21
Compliances
Communication Technologies
Electrical Characteristics
Supported Sensors and Functions
Table 5. Compliances
Certificates CE, FCC, ICES, UL/cUL, RoHs, REACH,
California, Title 24, and Prop65.
Standards EN 60730-1, EN 60730-2-9, EN
301489-1, EN 301489-17, EN
300328, EN 301893, EN 62479,
UL60730-1, UL60730-2-9, Title 47
part 15 subpart B, Title 47 part 15
subpart C, RSS 210, ICES-003
Table 6. Communication Technologies
BACnet IP Over Wi-Fi
Wi-Fi 802.11 b/g/n
Supported security levels
WPA,
WPA3_WAP2_AES,
WAP2_FBT_ENT,
WPA2,
WPA_ENT,
WPA2_FBT, and
WPA2_ENT
Bluetooth BLE 4.2 with 1 Mbps
Classic Bluetooth with
max. 3 Mbps
Sylk
TM
Honeywell Sylk
TM
Table 7. Electrical Characteristics
Rated Impulse Voltage 500 V
Construction of Control Independently Mounted
Control
Operation Method Type 1 Action
Pollution Degree 2
Purpose of Control Operating Control
Table 8. Supported Sensors and Functions
Sensors Options Part Numbers
Occupancy
Sensor
Direct
(Normally Open)
Reverse
(Normally
Closed)
Dry contact
occupancy sensor
Dirty Filter
Sensor
Direct
(Normally Open)
Reverse
(Normally
Closed)
DPS200, DPS400,
DPS1000
(Dry contact
differential
pressure switch)
Proof Of Air
Flow Sensor
Direct
(Normally Open)
Reverse
(Normally
Closed)
DPS200, DPS400,
DPS1000
(Dry contact
airflow switch)
Shutdown
Sensor
Direct
(Normally Open)
Reverse
(Normally
Closed)
Dry contact
shutdown switch
Mixed Air
Temperature
Sensor
NTC 20K, Type II
NTC 10K, Type II
Sylk
C7250
C7021
C7400S
Outdoor Air
Temperature
Sensor
NTC 20K, Type II
NTC 10K, Type II
Sylk
C7250A
C7021
C7400S
Return Air
Temperature
Sensor
Sylk C7400S
Discharge Air
Temperature
Sensor
NTC 20K, Type II
NTC 10K, Type II
Sylk
C7041
C7021
C7400S
Space
Temperature
Sensors
NTC 20K, Type II
Sylk
TR21
TR40/TR75 (max
4), TR120 (max 1)
Fan Current
Sensor Max
Amps
0~<+Inf Amps Coming soon
CO2 sensor
(analog)
0-10 VDC or Sylk
Sylk
C7232
TR40-CO2, TR42-
CO2
Proof of
waterflow
Digital Input Dry contact
waterflow switch
