AUTOMATIC OPPOSED BLADE DAMPERS (AOBD)
68-0246 2
ORDERING INFORMATION
When purchasin
g
replacement and modernization products from
y
our TRADELINE® wholesaler or distributor, refer to the
TRADELINE® Catalo
g
or price sheets for complete orderin
g
number.
If
y
ou have additional
q
uestions, need further information, or would like to comment on our products or services, please write or
phone:
1.
Your local Home and Buildin
g
Control Sales Office
(
check white pa
g
es of
y
our phone director
y)
.
2.
Home and Buildin
g
Control Customer Relations
Hone
y
well, 1885 Dou
g
las Drive North
Minneapolis, Minnesota 55422-4386
In Canada—Hone
y
well Limited/Hone
y
well Limitée, 35 D
y
namic Drive, Scarborou
g
h, Ontario M1V 4Z9.
International Sales and Service Offices in all principal cities of the world. Manufacturin
g
in Australia, Canada, Finland, France,
German
y
, Japan, Mexico, Netherlands, Spain, Taiwan, United Kin
g
dom, U.S.A.
SPECIFICATIONS
IMPORTANT
This specifications given in this publication do not
include normal manufacturing tolerances. Therefore,
this unit may not exactly match the listed specifica-
tions. Also, this product is tested and calibrated
under closely controlled conditions, and some minor
differences in performance can be expected if those
conditions are changed.
Models:
AOBD has a side-mounted motor.
AOBD-BM has a bottom-mounted motor.
IOBD has an internall
y
-mounted motor.
Available Sizes:
NOTE: For odd-size dampers, order a one-inch filler strip for
each odd dimension.
AOBD and IOBD:
— Sized usin
g
width b
y
hei
g
ht
(
AOBD motor and end plate
are mounted on the hei
g
ht dimension
)
.
— Even sizes are available for AOBD and IOBD from 6 x 4 in.
to 30 x 14 in.
AOBD-BM:
— Sized usin
g
hei
g
ht b
y
width
(
AOBD-BM motor is mounted
on the width dimension
)
.
— Even sizes are available for AOBD-BM onl
y
from 4 x 6 in.
to 14 x 20 in. without a filler strip but up to 14 x 30 in. with a
built-in filler strip.
(
When orderin
g
AOBD-BM dampers up
to 24 in. wide, a filler strip up to 4 in. is built-in.
)
Dimensions:
All damper sizes are built sli
g
htl
y
smaller than the listed
dimensions to ensure correct fit. See Fi
g
.1-3.
Fig. 1. AOBD dimensions in in. (mm).
2-1/8
(54)
3-1/4
(83)
3-5/8
(92)
2-3/8
(60)
M14848
LISTED
DAMPER
HEIGHT
5 (127)
WIDTH
HEIGHT
HEIGHT DIMENSIONS: 4, 6, 8, 10, 12, OR 14 IN.
(102, 152, 203, 254, 305, OR 356 MM).
TO ENSURE PROPER FIT, DAMPER HEIGHT
IS 3/16 IN. (5 MM) LESS THAN THE LISTED
HEIGHT DIMENSION.
WIDTH DIMENSIONS: 8, 10, 12, 14, 16, 18, 20, 22,
24, 26, 28, OR 30 IN. (203, 254, 305, 356, 406,
457, 508, 559, 610, 660, 711, OR 762 MM).
TO ENSURE PROPER FIT, DAMPER WIDTH IS
1/8 IN. (3 MM) LESS THAN THE LISTED WIDTH DIMENSION.
1
1
2
ADDITIONAL SIZES AVAILABLE (WIDTH X HEIGHT): 16X16, 18X16, 18X18, 20X16, 20X18, AND 20X20.
SIZES NOT AVAILABLE (WIDTH X HEIGHT): 8X10, 8X12, 8X14, 10X12, 10X14, AND 12X14.
LISTED DAMPER HEIGHT = ACTUAL AIR DUCT HEIGHT.
1
2
