4.2 Vacuum load
Diameter Vacuum load in mbar abs. at a process temperature of
[mm] 20ºC 40ºC 60ºC 80ºC
Hard rubber
Hard rubberHard rubber
Hard rubber
DN200...300 250 250 400 400
DN350...1000 500 500 600 600
DN1200...3000 600 600 750 750
Polypropylene
PolypropylenePolypropylene
Polypropylene
DN25...150 250 250 400 400
Diameter Vacuum load in psia at process temperature of
[inches] 68ºF 104ºF 140ºF 176ºF
Hard rubber
Hard rubberHard rubber
Hard rubber
8...12" 3.6 3.6 5.8 5.8
14...40" 7.3 7.3 8.7 8.7
48...120" 8.7 8.7 10.9 10.9
Polypropylene
PolypropylenePolypropylene
Polypropylene
1...6" 3.6 3.6 5.8 5.8
