ELECTRICAL DATA
Table 8: Electrical connection for Direct Burner Ignition systems
Supply voltage Coil indication Rectifier circuit
position
Coil connection ( fig. 1 ) Valve indication
24 Vac, 50/60 Hz 24 Vrac External Series connection pin1 and pin 5 or
plug 45.900.441-029
VK 81.5
24 Vac, 50/60 Hz 24 Vrac In plug Select plug 45.900.441- with rectifier
(See table 11)
VK 81.5
100 Vac, 50/60 Hz 100 Vrac External Series connection pin1 and pin 5 VK 41.5
110 Vac, 50/60 Hz 110 Vrac In S4575 Select plug 45.900.441-033
without rectifier (See table 11)
VK 41.5
In plug Select plug 45.900.441-039
(See table 11)
VK 41.5
External Series connection pin1 and pin 5 VK 41.5
220 ... 240 Vac, 50/60 Hz 220 ... 240 Vrac In S4565 Select plug 45.900.441-033
without rectifier (See table 11)
VK 41.5
In plug Select plug 45.900.441- with rectifier
(See table 11)
VK 41.5
External Series connection pin1 and pin 5 VK 41.5
Table 9: Electrical connection for Intermittent Pilot ignition systems
Supply voltage Coil indication Rectifier circuit
position
Coil connection ( fig. 1 ) Valve indication
24 Vac, 50/60 Hz 24 Vrac External Parallel connection pin1/2 and pin 4/5 VK 81.0
220 ... 240 Vac, 50/60 Hz 220 ... 240 Vrac In S4565 and
S4585 types
S4565 and S4585 types VK 41.0
220 ... 240 Vac, 50/60 Hz 220 ... 240 Vrac External Parallel connection pin1/2 and pin 4/5 VK 41.0
Table 10: Power consumption (W) and current (mA)
Supply voltage Power consumption Current
Nominal voltage 110% nominal voltage Nominal voltage 110% nominal voltage
1
st
operator
1
st
+ 2
nd
operator
1
st
operator
1
st
+ 2
nd
operator
1
st
operator
1
st
+ 2
nd
operator
1
st
operator
1
st
+ 2
nd
operator
DBI system
24 Vac, 50/60Hz -- 9.2 -- 11 -- 424 -- 466
100 Vac, 50/60Hz -- 9.75 -- 11.9 -- 105 -- 115
110 Vac, 50/60Hz -- 8.8 -- 10.8 -- 89 -- 98
220 Vac, 50/60Hz -- 9.4 -- 11.4 -- 48 -- 52
240 Vac, 50/60Hz -- 11.2 -- 13.6 -- 52 -- 57
IP system
24 Vac, 50/60Hz 6.7 6.7 + 3.1 8.0 8.0 + 3.7 309 309 + 143 340 157
220 Vac, 50/60Hz 9.1 4.8 11 5.8 46 24 51 27
240 Vac, 50/60Hz 10.9 5.7 13.1 6.9 50 26 55 29
220Vac, 50/60Hz 7 7 + 2.2 8.3 8.3 + 2.7 31 31 + 11 35 35 + 12.2
240 Vac, 50/60Hz 8.0 8.0 + 2.6 9.6 9.6 + 3.2 35 35 + 12.1 38.4 38.4 + 13.3
