EN2R-9004 0606R20-NE 4
DIMESIONAL DRAWING STANDARD CONNECTION
13.4
Pilot outlet M8 x 1-6H
for 4 mm tubing
24
Outlet
29.3
36.7
6.3 terminal (3)
148
VK.1..P/Q
(High/Low)
VK.1..A/C
(Standard regulator)
80
VK.1..E/T
(Throttle)
70
6.3 terminal (2)
148
VK.1..M/N
(Modureg)
24
Side outlet
Pressure tap (2)
Adjustable softlite
94.8
68.3
1
6
24.9
84.5
73
84.5
115
STEP
STEP
Hole Ø 2.6 to connect
ignition control
Throttle
Molex 1.1 square pin header
(mating connectors 3001 series)
113
17
12.5
25
Flange thread 1/2"
or 3/8" ISO7-1
16 mm full thread
VK.1..B/D
(Blank plate)
115
105
8
18
30
29.4
64.9
Mounting hole (2) for
tapping screws 3.9
DIN 7970
36.7
24.1
24
68.3
34.3
9.1
"0"-ring size
Ø 15.55 x Ø 15.55
M5 x 0.8(3)
6 mm full thread
Side outlet
(Optional)
Inlet
24
91
36.7
M4x0.7-6H(8)
6 min full thread
12
24
32
Ø 18.6
The cross hatched area
is sealing face without
imperfections
32
24
12
OUT
Earth terminal
21.9
IN
62
V1 V2
Tolerances according
to ISO 2768 mK
24
VK.1..M/N
(ModuPlus)
140
