XNX Universal Transmitter
Installation and Operation
93
Sensor Status
Figure 172. Sensor Status screen
Sensor Status displays the temperature of the sensor attached to the transmitter. When equipped with an EC or mV sensor, sensor
life is also displayed.
Figure 173. Sensor Temperature screen
Gas Data
Figure 174. Gas Settings screen
Gas Data displays the current detectable gas as congured for the attached sensor.
Figure 175. Gas Abbreviation and Full Scale screens
