Hand-held Cleaner
1. Multi-purpose nozzle
2. Dust cup
3. Dust cup latch
4. ON/OFF switch
5. Handle
6. Cord receptacle: for hand-held cleaner.
Upright Cleaner
7. Handle Grip
8. ON-OFF Switch: models without electronic speed control have a
two-speed switch.
9. Cord Storage Hooks: pull out lower hook and wrap cord around up-
per and lower cord storage hooks.
10. Bag Spring: place spring ring over hook to support the bag.
11. Air Freshener Dispenser: designed to hold a fragrance tablet and re-
lease a pleasant scent during cleaning. (Available on some models.)
12. Tool Storage Rack: may be attached to upright cleaner or stored
separately.
13. Vinyl Bag Jacket: covering for throw away bag.
14. Release Button: press to remove hand-held cleaner.
15. Electronic Speed Control Module: available on some models.
16. Carrying Handle
17. Cord Receptacle: for upright cleaner
18. Handle Release Pedal: step on either pedal to lower handle to either
operating or low position.
19. Twin Headlight
20. Carpet Height Adjustment Lever: choose "LOW/MEDIUM",
"PLUSH", or "SHAG".
21. Molded Furniture Guard
22. Edge Cleaning: brushed edge cleaning is provided on the right side
of the cleaner; standard edge cleaning is provided on the left side.
Note: If using cleaner on new carpet, be sure to change bag frequently.
See "Maintenance" section for bag replacement.
Operate cleaner only at voltage specified on data plate on bottom of
cleaner. 4
