Maintenance
NOZZLE: HOW TO CLEAN AND STORE
1. To prevent possible leaking, remove and empty Clean Water Tank and Dirty Water Tank.
2. With handle in upright position, tilt carpet cleaner back so that handle rests on the floor.
3. Rotate Nozzle latch to unlock position (Fig. E).
Figure: E
4. Pull up on Nozzle slightly to unsnap Nozzle from foot of carpet cleaner.
5. Pull Nozzle forward to remove from carpet cleaner. Be sure the Nozzle does not get caught on Recovery Tank
Latch (Fig. F).
Figure: F
