16
Remove (6) screws on
bottom plate with a
Phillips screwdriver.
Pivot off the
bottom plate.
Remove worn belt
and slide new belt
with lettering on the
outside over the motor
shaft.
Push other end of new
belt around brushroll
area without bristles.
Replace bottom plate
and reinsert screws.
Lower handle and
vacuum flip over.
3
Keep your Rewind Running Properly: Replacing Belt
Any other servicing should be done by an authorized service representative. If appliance is not working as it should,
has been dropped, damaged, left outdoors, or dropped into water, take it to a service center prior to continuing use.
The belt is located under the cover of the vacuum and should be checked often. Replace belt if it stretched, cut or broken.
4
2
1
5
What to buy: Belt
If desired, additional belts can be purchased at Hoover.com or 1-800-944-9200.
When purchasing a new belt for models ask for Hoover
®
Belt part No. 38528058
CAUTION
To reduce the risk
of injury from moving parts
- Unplug
before servicing.
