C
Reposition bag door by placing tabs on
bottom of door into opening (C).
Press top of door to snap securely shut.
Replacing bag door
B
3-6
Removing and replacing filter
Lift out filter (B) and hand wash it in cold
water with mild detergent.
Let filter air dry and reposition it on the
side of cleaner. Make sure green colored
side of filter faces outward.
Reposition bag door.
Should you want to replace this filter, ask
for HOOVER part No. 38766008.
Do not operate cleaner without either
the secondary or final filter in place.
Check agitator shield
Because your cleaner picks up so well,
we strongly recommend you check for
debris accumulation under the agitator
shield each time you clean the filters.
Removing debris under the shield will
help maintain your cleaner’s excellent
pick up and suction. Remove debris as
follows:
1. Disconnect cleaner from electrical
outlet.
2. Check for dirt accumulation by
removing bottom plate (Fig. 3-10),
removing agitator, (Fig. 3-11) and lifting
agitator shield (Fig. 3-13).
3. Remove any debris and replace
shield, agitator and bottom plate (Figs.
3-13 to 3-15).
Cleaning secondary filter
Disconnect cleaner from electrical
outlet.
The secondary filter (A), located behind
the grill in the bottom of bag compart-
ment, protects the motor from dirt
particles.
If filter becomes dirty, pull off grill and lift
out filter.
Hand wash filter in cold water with mild
detergent, then air dry.
Reposition dry filter and grill.
Should you want to replace this filter, ask
for HOOVER part No. 38765019.
Cleaning final filter
The final filter assists in the filtration
process to return clean air to the room.
To remove this filter when it becomes
dirty, remove bag door and pull down top
of filter.
