Remove all parts from carton and
identify each item shown. Make sure
all parts are located before disposing
of packing.
A. or B. Handle section
C. Cleaner body
D. Hose, cleaning tools and wands
E. Crevice wand (included with some
models instead of crevice tool)
F. Handle bolts and nuts packet
(in bag with owner's manual)
1-1
A
Slide handle onto cleaner body.
Push bolts into holes on back of
handle.
Remove bag door on cleaner body
by pushing down at top of door and
pulling door outward.
Switch (A) above bag door should
be in OFF position.
1-2
1-3 1-4
STEP I Attach handle
D
C
B
G
F
H
A
Carton Contents
(U.S. only) OR
1-330-499-9499 to speak with a representative in our Consumer
Response Center OR
Visit us on-line at www.hoover.com to find the service
outlet nearest you (click on the "Service" button).
Not required for assembly:
G. Extra filter bag (one already
installed in cleaner)
H. Extra belt (one already installed
in cleaner)
E
To Next Page
