Float Set
EN
3
Assemble the Float Set
1. Determine left and right oats and front and rear landing
gear struts. There is a notch on the inside of the oats to
make room for the landing gear struts and spreaders, as
shown in the diagram.
3. Insert the landing gear struts and spreaders into the
mounting brackets. There are at spots at the mounting
points on the struts and spreaders. Ensure the wires
are located so the securing screws will engage the at
spots.
2. The spreaders should be installed on the inner mounting
locations, and the landing gear struts should be located
in the outer front and aft mounting locations.
Specifications
Length 23.4" (595mm)
Width
Each Float: 3.5” (90mm)
Assembled Float Set: 14.8” (378mm)
Weight
Floats Only: 4.76oz (135g)
Wire Struts: 1.57oz (44.4g)
Hardware: 0.35oz (10g)
To Next Page
