TR10A108-B RE / 02.2013
35
7 Teaching in the operator
When teaching in (Figure 21), the operator is adjusted to the
door. The travel length, required force for opening and closing,
and any connected safety devices are automatically taught in
and saved in a power failure-proof manner. The data are only
valid for this door.
Operator light:
If the operator has not been taught in, the operator light will be
illuminated for 60 seconds as soon as the mains plug is
inserted in the socket. Pressing the buttons
, or PRG
extends the time the light is on.
The operator light flashes during the teach-in process. After
the learning runs have been completed, the operator light is
illuminated and switches off after 60 seconds (factory setting).
CAUTION
Danger of injury due to selection of the wrong door type
If the wrong door type is selected, unspecific values will be
pre-set. The resulting door malfunctions may cause injuries.
Only select the menu that corresponds to the available
▶
door type.
WARNING
Danger of injury due to faulty safety equipment
In the event of a malfunction, there is a danger of injury due
to faulty safety equipment.
After the learning runs, the person commissioning the
▶
system must check the function(s) of the safety
equipment.
The system is ready for operation only after this.
8 Hand transmitter HS 5 BiSecur
WARNING
Danger of injury during door travel
Persons may be injured by door travel if
the hand transmitter is actuated.
Make sure that the hand transmitters
▶
are kept away from children and can
only be used by people who have
been instructed on how the remote-
control door functions!
If the door has only one safety
▶
device, only operate the hand
transmitter if you are within sight of
the door!
Only drive or pass through remote
▶
control door systems if the door is in
the Open end-of-travel position!
Never stay standing under the open
▶
door.
Please note that unwanted door
▶
travel may occur if a hand
transmitter button is accidentally
pressed (e.g. if stored in a pocket /
handbag).
CAUTION
Danger of injury due to unintended door travel
Unintended door travel may occur while teaching in the
radio system.
Make sure no persons or objects are in the door's area
▶
of travel when teaching in the radio code.
CAUTION
Danger of burns from the hand transmitter
If exposed to direct sunlight or great heat, the hand
transmitter may heat up so much that burns could occur
during use.
Protect the hand transmitter from direct sunlight and
▶
great heat (e.g. by placing it in a stowage compartment
in the dashboard).
ATTENTION
Functional impairment due to environmental influences
Non-compliance with these instructions can impair the
function!
Protect the hand transmitter from the following conditions:
Direct sunlight (permissible ambient temperature: ō
– 20 °C to + 60 °C)
Moistureō
Dustō
NOTES:
If there is no separate garage entrance, perform all ō
programming changes and extensions of radio systems
from inside the garage.
After programming or extending the radio system, check ō
the functions.
Only use original components when putting the radio ō
system into service or extending it.
Local conditions may affect the range of the radio system.ō
ENGLISH
