40
TR10A108-B RE / 02.2013
Tension of the toothed belt11.1
The toothed belt of the operator boom
is tensioned optimally ex-factory.
With large doors it is possible that the
belt will briefly hang out of the boom
profile during the start-up and slow-
down phases. However, this does not
constitute a technical malfunction and
does not negatively affect the function
and service life of the operator.
11.2 Replacement bulb
Type Cold-light reflector
lamp with safety
glass and
UV protection
Socket GU 5.3
Nominal power 20 W
Nominal voltage 12 V
Angle of
reflected beam
36° – 60°
Diameter 51 mm
Lamp colour Clear
If the light is switched on, an alternating
current of 12 V AC is present at the lamp
socket.
Exchange the cold-light reflector
▶
lamp only if the operator is voltage-
free.
12 Factory reset
See Figure
▶
32
To reset to the factory settings:
Disconnect the mains plug and, if 1.
applicable, the plug of the
emergency battery.
Press and hold the 2. PRG button.
Reconnect the mains plug.3.
The following is illuminated in
the display
8.8.– for one second
C– for one second
then – U
Release the 4. PRG button.
The operator light flashes once and
then remains illuminated.
Adjust the operator and teach it 5.
in (see section 5).
If the factory reset was not successful,
the operator will automatically go back
to operation mode.
NOTE:
The taught-in radio codes (impulse/light/
partial opening) are not changed.
To delete all radio codes:
See section
▶
6.1.12
ENGLISH
