5.15 Enable AutoRun

“Enable AutoRun” displays the following options which can be selected:

Enable AutoRun

No = OCS will be in IDLE mode after AutoLoad or Automatic Restore.

Yes = OCS will automatically be placed into RUN mode after AutoLoad or

Automatic Restore.
