Appendix B: Menu configuration ComPass B
("!" behind the corresponding values in the ComPass B if the ComPass has not been calibrated.)
("!" behind the corresponding values in the ComPass B if the ComPass has not been calibrated.)
► Reset Display? ◄ No Yes ►
◄ Back
► z.B. 00020 I>> 123 A ▲Up ▼Down ◄◄ Back
► I>>/A (z.B. 400 A) ▲Up ▼Down ◄ Cancel Save ►
► tI>>/ms (z.B. 80 ms) ▲Up ▼Down ◄ Cancel Save ►
► IE>/A (z.B. 200 A) ▲Up ▼Down ◄ Cancel Save ►
▼ Events
▼ Settings
▼ tI>>/ms
► I>>/A
▼ IE>
► L1 L2 L3 E Status: OK
L1 L2 L3 E Status: uncalibrated
L1 L2 L3 E Status: Battery low
L1 L2 L3 E Status: Conf. Error
L1 L2 L3 E Status: Device Error
Date, event no., time, fault type,
fault current I1,I2,I3.IE, I1 LGKC, I2 LGKC, I3 LGKC
L1 L2 L3 E Status: OK
▼ I1, I2, I3 I(E) in A
▼ V12, V23, V31, V(NE) in KV
▼ Load Flowdirection (A/B)
▼ S/kVA, P/kW, Q/kVAr, cos phi in degree (Ind./Cap.)
▼ Frequency in Hz
▼ I1 Ø15min, I2 Ø15min, I3 Ø15min, I(E) Ø15min in A
▼ I1 max24h, I2 max24h, I3 max24h in A
▼ I1 max7D, I2 max7D, I3 max7D in A
▼ I1 max365D, I2 max365D, I3 max365D in A
▼ I1 max LR, I2 max LR, I3 max LR in A (LR=Last Reset)
► Reset Display
▼ Measurement
◄ ◄ L1 L2 L3 E Status: OK
