WIRING CONNECTIONS - After Date Code 46
J1
J4
J3
J2 J9J15 J10 J16 J5 J8 J11
1 2 1 2 1 2 123421
3 2 1 1-3 4-5 1-3 4-6 7-9 11-12948576
1 2 3 4 5 6 1 2 3 4 5
P
T MV
NTC
NTC
4
Wash Heating Element
12
11
16
14
3
2
Pressure Switch
Overflow
Shared
Full
Empty
Standard Door Lock
220V Power Supply
Dryer Heating Element
Thermoprotector
Tacho
SV Dryer
Fan
SV Wash
SV Pre-Wash
NTC Dryer
NTC Wash
Pump with standard Door Lock
Conductivity Sensor
Communication Interface
LN
Motor Winding
J10 Wiring Colours
1 + 3 Orange - Cold Dryer Valve
4 + 6 Violet - Dryer Fan
7 + 8 Black - Dry Thermistor
J8 Wiring Colours
1 + 3 White - Cold Fill Valve
4 + 6 Blue - Cold Pre-Wash
11 + 12 Blue - Wash Thermistor
Serial Port EEProm
To Next Page
