Hotpoint Aquarius Plus+ WD640P User Manual

25
WIRING CONNECTIONS - From Serial No. 60508.0000
J1
J4
J3
J2 J9J15 J10 J16 J5 J8 J11
1 2 1 2 1 2 123421
3549812 21 461 3 7 8 1-3 4-6 7-9 11-1276
1 2 3 4 5 6 1 2 3 4 5
P
T MV
NTC NTC
4
Wash Heating Element
12
11
16
14
3
2
Pressure Switch
Overflow
Shared
Full
Empty
Standard Door Lock
220V Power Supply
Dryer Heating Element
Thermoprotector
Tacho
Flushing Valve
Condenser Valve
Dryer NTC
Dryer Motor
SV Wash
SV Pre-Wash
NTC Wash
Pump with 5 pin Door Loc k
P
Pump with standard door lock 3 pins
Conductivity Sensor
Communication Interface
LN
Motor Winding
