Service Manual UK
Indesit
Company
English
TECHNICAL SPECIFICATIONS
Models FDYF11011G 82748 Graphite
FDYF11011K 82752 Black
FDYF11011P 82746 White
First Production 2013
Energy Class A+
Washing Class A
Drying Class A
Noise Level 49 dB
Country of Origin Poland
Dimensions Height - 850 mm
Width - 600 mm
Depth - 600mm
Capacity 13 place settings
Electrical Supply 220/240 Volts AC @ 50Hz
Cable Length: 1.28 Metres
Energy Consumption Off Mode: 0.5 Watts
(2011 Regulations) Left On Mode: 5 Watts
Standard Cycle: 1.04 kW/h
Water Consumption Standard Cycle: 11 litres
Drying Natural Drying
Controls Electronic DEA 700 or DEA603 (Industrial Code ending ’2500’ )
Tub Stainless Steel
Heater type Flow through type with built in safety cut out and fuse
Heater Wattage 1.8 kW @ 230V AC
Heater Resistance 29.20Ω
Circulation Motor Synchronous
Detergent Dispenser Capacity 25g + 5g ** only available as part of the door panel
Rinse Aid Dispenser Capacity 140ml
Fill Valve Resistance 3.72 KΩ approx.
Water Pressure 0.56 bar (Max 10 bar)
Regeneration Valve 4.1 KΩ approx.
Drain Pump Synchronous motor
Power Consumption: 26 Watts
Thermistor Sump Mounted
Wash Programmes 8 - Eco, Auto Intensive, Auto Normal, Auto Fast, Duo Wash,
Delicates, Express 30’, Soak.
Wash Temperatures Between 50
°C and 70°C
Salt Refill Indicator Symbol on display
Rinse Aid Indicator Symbol on display
Supply Water Pressure 0.5 to 10 Bar (7.25 psi - 145 psi)
