If the model is not vented
to the outside, the air will
be recirculated through a
disposable charcoal filter
that helps remove smoke
and odors.
The charcoal filter should
be replaced when it is
noticeably dirty or
discolored (usually after
6–12 months, depending
on hood usage). See
“Optional Kits,” page 9, for
more information.
The charcoal filter
cannot be cleaned. It
must be replaced. Order
Part No. WB02X11124
from your Mabe Canada
supplier.
Charcoal Filter
(on some models)
To remove the charcoal
filter, disconnect power at
the main fuse or circuit
breaker panel or pull the
plug.
Remove the front grille by
backing out the 3 screws
along the top. Slide the
grille to the left, then pull
straight out. Slide the filter
toward the front of the
oven and remove it.
To Remove
Charcoal Filter
Remove 3 grille screws
at the top of the oven.
To install a new filter,
remove plastic and other
outer wrapping from the
new filter.
Insert the filter into the top
opening of the oven as
shown. It will rest at an
angle on 2 side support
tabs and in front of the
right rear tab. Replace the
grille and 3 screws.
To Install
Charcoal Filter
Helpful Information
The Exhaust Feature
34
