GLEAM
™
(Model GLM)
Dimensions
NOTE: All dimensions are approximate; measure your spa
before making critical design or pathway decisions.
NOTE: Watkins Manufacturing Corporation recommends that the Gleam be installed on a minimum 4” (10 cm) thick
reinforced concrete pad or structurally sound deck able to support the “dead weight” found in the spa specification
chart.
WARNING: The Gleam must not be shimmed in any manner.
GLEAM
110" (279 cm)
91"
(231cm)
3.5" (8.9 cm)
34.5" 87.6 cm)
38" (96.5 cm)
65 1/2" (166.4 cm)
20” (50.8 cm)
95” ( 241.3 cm)
49.5” (125.7 cm)
(Bottom view)
(Front view)
Upside Down View
of Spa
Drain
Electrical Cutout 1.5" (4.4 cm)
Door DoorDoor
