23Hotsy 1700 Operator’s Manual 8.914-380.0 - W
Exploded View Parts List
REF PART NO. QTY DESCRIPTION NOTES
73 9.803-100.0 1 SLIDER ASSY, CW CABINET, WRINKLE BLACK
74 9.802-776.0 4 NUT, 5/16” ESNA
- 9.802-777.0 4 NUT, 5/16” ESNA (FOR SS OPTION)
75 8.706-207.0 1 ELBOW, 3/8” STREET STEEL
(TIME DELAY OPTION )
76 9.802-045.0 1
BUSHING, 1/2” X 3/8” STEEL (AUTO START OPTION, (1753,
1754, 1755)
77 9.800-034.0 1 CLEAR LEXAN
78 8.901-136.0 1 DETERGENT LABEL
79 9.802-067.0 4 BUMPER PAD
80 9.802-073.0 84” WEATHER STRIPPING
81 9.802-074.0 4 NUT, 1/4” SQUARE
82 9.802-151.0 4 SWIVEL, 1/2” JIC FEM. PUSH-ON
83 9.802-424.0 30’ CORD, 16-4 SERVICE
84 9.802-695.0 4 NUT, 10/32” KEPS (ONLY 1710)
- - 7 NUT, 10/32” KEPS (1723, 1724, 1725, 1744, 1745, 1754, 1755)
- - 10 NUT, 10/32” KEPS (1720, 1722, 1743, 1753)
85 9.802-723.0 4 BOLT, 3/8” X 1-1/2” NC HH
- 9.802-724.0 4 BOLT, 3/8" X 1-1/2", HH NC SS
86 9.802-759.0 10
SCREW, 10/32" X 1/2" BLACK (1723, 1724, 1725, 1744, 1745,
1754, 1755)
- - 11 SCREW, 10/32" X 1/2" BLACK (1720, 1722, 1743, 1753)
87 9.802-762.0 2 SCREW,
10/32" X 1-1/4" ( ONLY 1710)
--1
(AUTO START OPTION, ALL MODELS
EXCEPT 1710)1
88 9.802-773.0 4 NUT, 1/4" ESNA NC
- 9.802-774.0 - NUT, 1/4", ESNA, NC, SS (SS OPTION)
90 9.802-794.0 8 CAGE NUT, 1/4" X 12 GAUGE
91 9.802-811.0 4 WASHER, 3/8" X 1-1/2" FENDER
- 9.802-812.0 4 WASHER, 3/8" X 1-1/2", SS (SS OPTION)
92 9.800-040.0 2 LABEL, GROUND
93 9.803-032.0 1
STANDOFF, ELECTRICAL BOX (ALL MODELS EXCEPT
1710)
94 9.802-520.0 1 STRAIN RELIEF, 3/4" (1710, 1720, 1722,1723, 1724, 1725)
- 9.802-522.0 1 STRAIN RELIEF, 1" (1743, 1744, 1745, 1753, 1754, 1755)
95 9.802-472.0 1
TIMER, SOLID STATE, 120V 5-60 MIN. ADJUST. (AUTO
START OPTION)
96 9.802-514.0 1 STRAIN RELIEF, 1/2" (AUTO START/TIME DELAY OPTION)
- 9.802-524.0 1 LOCKNUT, 1/2" (AUTO START/TIME DELAY OPTION) NOT SHOWN
97 9.804-595.0 1 END BRACKET
98 8.716-125.0 1 SWITCH, PRESSURE BLOCK (TIME DELAY OPTION)
99 8.751-306.0 1 TIMER, MULTI-FUNCTION (TIME DELAY OPTION)
100 8.706-294.0 1
BUSHING, 1/2" X 3/8" STEEL (TIME DELAY OPTION, 1753,
1754, 1755)
