Exploded View Parts List
REF PART NO. QTY DESCRIPTION NOTES
101 9.802-779.0 4 NUT, 3/8” ESNA NC
- 9.802-780.0 4 NUT, 3/8”, ESNA, NC, SS (SS OPTION)
102 9.802-259.0 12" HOSE, 1/2” PUSH-ON
103 8.718-986.0 4 WASHER, 3/8” SAE FLAT (ALL EXCEPT 1710)
- 8.718-980.0 4 WASHER, 5/16” SAE FLAT (ONLY 1710)
104 9.804-057.0 4 WASHER (ALL EXCEPT 1710)
- 9.802-813.0 4 WASHER, 5/16” LOCK, SPLIT (ONLY 1710)
105 9.804-058.0 4 BOLT, PUMP MOUNTING (ALL EXCEPT 1710)
- 9.802-741.0 4 BOLT, 8 MM X 16 MM HEX HEAD (ONLY 1710)
106 9.802-802.0 8 WASHER, 1/4” FLAT SAE, ZINC
107 9.802-700.0 4 BOLT, 1/4” X 3/4” NC HH (612937)
108 8.718-568.0 WASHER, 1/4” FLAT, RUBBER BACK, SS
