Hoveround MPV4 - Joystick Controllers Explained

14
Chapter 1
D82008204 REV B 1/14/04
Joystick Controllers
All the controls and indicators necessary to drive your MPV 4 are located on the
joystick controller. Your MPV 4 may be equipped with one of the following joystick
controllers.
Figure 1A - VSI Figure 1B - Pilot
Figure 1C - Commando
