Hoymiles DTU-W100 3rd Gen User Manual

© 2019 Hoymiles Converter Technology Co., Ltd. All rights reserved. 12
DTU-W100 3 Gen
Note: Network Connection:
1. Connected to Wi-Fi, the blue indicator lights up, and then you can build the power station;
2. Can't connect to Wi-Fi, the indicator lights up as red + blue alternately flashing, and then you need to
connect to Wi-Fi again.
11. Datasheet
but without ID
inside.
LED flashes
in Blue
every 1
second:
No ID
 Complete networking
Green
LED lights
up in Green
every 0.5
seconds:
The search ID
is incomplete

Re-locate the DTU to somewhere close to both
router and Microinverter
Model
DTU-W100
Communication to Microinverter
Communication method
2.4GHz Proprietary RF (Nordic)
Maximum distance (open space)
150m
Maximum number of inverters connected
99 panels
Communication to Cloud
WIFI communication standard
WiFi (802.11b/g/n)
Data upload time
15 minutes
Power Supply (Adapter)
Power supply
External Adapter with USB port
Adapter input voltage/frequency
100 to 240 V AC / 50 or 60Hz
Adapter output voltage/current
5V / 2A
Power consumption
1.0W (typical), 5W(maximum)
Mechanical Data
Ambient temperature range (°C)
-20°C to 55°C
