Hoymiles HM-1200 User Manual

Hoymiles HM-1200
29 pages
To Next Page IconTo Next Page
To Next Page IconTo Next Page
Page #1 background imageLoading...
Page #1 background image
Version 1.0 (June 2020)

Other manuals for Hoymiles HM-1200

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Hoymiles HM-1200 and is the answer not in the manual?

Hoymiles HM-1200 Specifications

General IconGeneral
ModelHM-1200
CategoryInverter
Max Output Power1200 W
Input Voltage Range16 V - 60 V
Max DC Input Voltage60V
Efficiency96.5%
Weight4.3 kg
Operating Voltage Range16 V - 60 V
Maximum Input Voltage60V
Nominal Output Power1200 W
Power Factor>0.99
THD<3%
Enclosure RatingIP67
AC Output Frequency50 Hz / 60 Hz
Cooling MethodNatural Convection
MPPT Voltage Range16V-60V
Nominal Output Voltage/Range230VAC
Nominal Output Current5.2A
Ambient Temperature Range-40°C to +65°C
AC Output Voltage230 V
