Foot assembly
Description Spare part number
Foot assembly 669986-001
The foot assembly is secured with six screws. On each side, the inside screw is smaller than the two
outside screws.
To remove the foot assembly:
1. Prepare the computer for disassembly (see
Preparing to Disassemble the Computer
on page 37).
2. Remove the rear cover (see
Rear Cover on page 38).
Foot assembly 41
