a. Remove the two Phillips M2.0×3.0 screws (1) that secure the display panel to the top of the
enclosure.
b. Remove the four broad head Phillips M2.5×3.0 screws (2) that secure the display panel to the
bottom of the enclosure.
c. Remove the cover plates (1) and the display brackets (2).
d. The panel is secured to the display enclosure with long strips of tape. Pull the tape out from under
each side of the display panel (1).
NOTE: You have to pull on the tape multiple times before it is completely removed.
32 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
