2. Press down on the module until the side retention clips snap into place (3).
Speaker, right
To remove the right speaker, use this procedure and illustration.
Table 5-5 Right speaker description and part number
Description Spare part number
Speaker, right M57164-001
Before removing the right speaker, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 31).
2. Remove the bottom cover (see Bottom cover on page 31).
3. Disconnect the battery cable from the system board (see Battery on page 32).
Remove the right speaker:
1. Remove the two Phillips M2.0 × 2.5 screws from the speaker (1).
Component replacement procedures 37
