Appendix A Chassis views and technical
specifications
Chassis views
1620-8G
Figure 20 1620-8G front panel
(1) 10/100/1000BASE-T auto-sensin
g
Ethernet port (2) Console port
(3) Port LEDs (4) Power LED
Figure 21 1620-8G rear panel
(1) Groundin
g
screw (2) AC power receptacle
(3) Security slot
1620-24G
Figure 22 1620-24G front panel
(1) 10/100/1000BASE-T auto-sensing Ethernet port (2) Port LEDs
(3) Power LED (4) Console port
