HP 1620 Series User Manual

20
Figure 23 1620-24G rear panel
(1) Grounding screw (2) AC power receptacle
1620-48G
Figure 24 1620-48G front panel
(1) 10/100/1000BASE-T auto-sensin
g
Ethernet port (2) Port LEDs
(3) Power LED (4) Console port
Figure 25 1620-48G rear panel
(1) Groundin
g
screw (2)
A
C power receptacle
Physical specifications
Chassis dimensions and weights
Chassis Dimensions (H × W × D) Wei
g
ht
1620-8G 44 × 266 × 162 mm (1.73 × 10.47 × 6.38 in) ≤ 1 kg (2.20 lb)
1620-24G 44 × 440 × 173 mm (1.73 × 17.32 × 6.81 in) ≤ 2.2 kg (4.85 lb)
1620-48G 44 × 440 × 238 mm (1.73 × 17.32 × 9.37 in) ≤ 3.3 kg (7.28 lb)

HP 1620 Series Specifications

General

Power Supply	Internal
Form Factor	Desktop or Rack-mountable
Management	Unmanaged
MAC Address Table	8192 entries
Model	HP 1620 Series
