3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 39), and then remove the following components:
●
Optical drive (see
Optical drive (select models only) on page 40)
●
WLAN module (see
WLAN module on page 43)
●
Keyboard (see
Keyboard on page 49)
●
Top cover (see
Top cover on page 51)
●
USB board (see
USB board on page 58)
●
Power connector cable (see
Power connector cable on page 59)
Remove the display assembly:
1. Disconnect the display panel cable (1) from the system board.
2. Release the wireless antenna cables from the clips (2) built into the base enclosure.
CAUTION: Support the display assembly when removing the following screws. Failure to
support the display assembly can result in damage to the display assembly and other computer
components.
3. Remove the four Phillips PM2.5×6.0 screws (3) that secure the display assembly to the
computer.
4. Remove the display assembly (4).
Component replacement procedures 63
