Mounting the Monitor (Optional)
The monitor panel can be attached to a VESA mount kit provided with select models. To attach the
VESA mount kit, use the following steps.
NOTE: This apparatus is intended to be supported by UL or CSA Listed wall mount bracket.
CAUTION: This VESA mount kit supports the VESA industry standard 100 mm mounting holes. To
attach a third-party mounting solution to the VESA mount, four 4 mm, 0.7 pitch, and 10 mm long
screws are required. Longer screws must not be used because they may damage the monitor. It is
important to verify that the manufacturer’s mounting solution is compliant with the VESA standard and
is rated to support the weight of the monitor display panel. For best performance, it is important to use
the power and video cables provided with the monitor.
Removing the Monitor Stand
You can remove the monitor panel from the stand to install the panel on a wall, a swing arm, or other
mounting fixture.
CAUTION: Before beginning to disassemble the monitor, be sure the monitor is turned off and all
cables are disconnected.
1. Disconnect and remove all cables from the monitor.
2. Adjust the monitor to the vertical position.
3. Lay the monitor face down on a flat surface covered by a clean, dry cloth.
4. Press down on the release latch (1) and slide the stand out of the slot on the display head (2).
Mounting the Monitor (Optional) 13
