Page #52 background imageLoading...
Page #52 background image
Display subcomponents (bezel, webcam, panel)
This section describes removing display subcomponents that do not require that you remove the entire
display assembly from the computer. You can remove the display bezel, webcam/microphone module, and
display panel while the display assembly is still attached to the computer.
To remove the remaining display subcomponents, you must remove the entire display assembly from the
computer. See
Display assembly on page 61 for more information about removing the display assembly in
its entirety.
Description Spare part number
Raw display panel for use in HP 14 and Compaq 14 models 747257-001
Raw display panel for use in HP 240 models and HP 245 models 749035-001
Display bezel for use with HP 14 models 747237-001
Display bezel for use with Compaq 14 models 747238-001
Display bezel for use with HP 240 and HP 245 models 749551-001
Webcam/microphone module 747144-001
Before removing display subcomponents while the display assembly is still attached to the computer, follow
these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 43).
To remove the display bezel, webcam/microphone module, and raw display panel:
1. Position the computer upright with the front toward you, and then open it.
44 Chapter 4 Removal and replacement procedures
