If you have replaced the hard drive, you can use the Factory Reset option of HP Recovery media to
restore the factory image to the replacement drive. For more information, see
Recovering using HP
Recovery Manager on page 109.
If you wish to remove the recovery partition to reclaim hard drive space, HP Recovery Manager offers
the Remove Recovery Partition option.
For more information, see
Removing the HP Recovery partition on page 110.
Recovering using HP Recovery Manager
HP Recovery Manager software allows you to recover the computer to its original factory state by using the
HP Recovery media that you created or by using the HP Recovery partition (select models only). If you have
not already created recovery media, see
Creating HP Recovery media on page 107.
Using HP Recovery media, you can choose from one of the following recovery options:
System Recovery—Reinstalls the original operating system, and then configures the settings for the
programs that were installed at the factory.
Minimized Image Recovery (select models only)—Reinstalls the operating system and all hardware-
related drivers and software, but not other software applications.
Factory Reset—Restores the computer to its original factory state by deleting all information from the
hard drive and re-creating the partitions. Then it reinstalls the operating system and the software that
was installed at the factory.
The HP Recovery partition (select models only) allows System Recovery and Minimized Image Recovery.
What you need to know
HP Recovery Manager recovers only software that was installed at the factory. For software not
provided with this computer, you must either download the software from the manufacturer's website
or reinstall the software from the media provided by the manufacturer.
Recovery through HP Recovery Manager should be used as a final attempt to correct computer issues.
HP Recovery media must be used if the computer hard drive fails. If you have not already created
recovery media, see
Creating HP Recovery media on page 107.
To use the Factory Reset option, you must use HP Recovery media. If you have not already created
recovery media, see
Creating HP Recovery media on page 107.
If the HP Recovery media does not work, you can obtain recovery media for your system from support.
See the Worldwide Telephone Numbers booklet included with the computer. You can also find contact
information from the HP website. Go to
http://www.hp.com/support, select your country or region, and
follow the on-screen instructions.
IMPORTANT: HP Recovery Manager does not automatically provide backups of your personal data. Before
beginning recovery, back up any personal data you wish to retain.
Using the HP Recovery partition (select models only)
The HP Recovery partition (select models only) allows you to perform a system recovery or minimized image
recovery without the need for recovery discs or a recovery USB flash drive. This type of recovery can only be
used if the hard drive is still working.
To start HP Recovery Manager from the HP Recovery partition:
IMPORTANT: For tablets, connect to the keyboard dock before beginning these steps (select models only).
Restore and recovery 109

Table of Contents

Other manuals for HP 240 G2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP 240 G2 and is the answer not in the manual?

HP 240 G2 Specifications

General IconGeneral
Form factorClamshell
Product typeLaptop
Product colorBlack
Country of originChina
Bus typeDMI
SteppingL1
Tjunction90 °C
Processor cache3 MB
Processor cores2
Processor modeli3-3110M
System bus rate5 GT/s
Processor familyIntel® Core™ i3
Processor seriesIntel Core i3-3100 Mobile Series
Processor socketBGA 1023
Processor threads4
Processor codenameIvy Bridge
Processor frequency2.4 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)35 W
CPU multiplier (bus/core ratio)24
Maximum number of PCI Express lanes16
Motherboard chipsetIntel HM76 Express
Memory slots2x SO-DIMM
Internal memory4 GB
Memory clock speed1600 MHz
Memory form factorSO-DIMM
Internal memory typeDDR3-SDRAM
Maximum internal memory- GB
Memory layout (slots x size)1 x 4 GB
HDD speed5400 RPM
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi DL
Card reader integratedYes
Total storage capacity500 GB
Compatible memory cardsSD
Number of HDDs installed1
Display surface-
Display diagonal14 \
Display resolution1366 x 768 pixels
Native aspect ratio16:9
On-board graphics card ID0x166
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 4000
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency650 MHz
On-board graphics card dynamic frequency (max)1000 MHz
Front camera resolution1280 x 720 pixels
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version4.0
Ethernet LAN data rates10, 100, 1000 Mbit/s
Charging port typeDC-in jack
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 2.0 ports quantity0
Pointing deviceTouchpad
Operating system installedWindows 8.1
Processor codeSR0N2
Processor ARK ID65700
Processor package size37.5 x 37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction setsAVX
Intel Identity Protection Technology version1.00
Battery capacity41 Wh
Battery life (max)- h
AC adapter power65 W
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth240 mm
Width346 mm
Height28.1 mm
Weight2200 g
